SmallRig 4287 Professional Video Head PH8
5,999 kr
Aluminium fluid video head for up to 8 kg, equipped with a 6-stage counterweight system and adjustable hydraulic damping.
In stock
SmallRig 4287 Professional Video Head PH8
A fluid video head made of aluminium for professional use, supporting loads up to 8 kg.
The head measures 168 mm in height and weighs 1.8 kg. It features 360 ° panning and a tilt range of 150 ° with a tilt interval of +90°/-60°. The tripod mount is available as 3/8″ or 1/4″.
Damping and balance
A 6-stage counterweight system balances cameras or rigs up to 8 kg when the centre of gravity height is 55 mm. Panning and tilt are controlled via a hydraulic damping system with 4 stages for each movement. The detachable telescopic handle can be rotated and attached to either the right or left side, with a length of 35.0-53.0 cm.
Plate and compatibility
The Touch-and-Go quick release plate allows the camera to be clicked into place without adjustments. The head is compatible with the Manfrotto 501PL quick release plate and 75 mm bowl adapters.
Included in the box
- PH8 fluid head
- Allen key
- Manual
Specifications
| Manufacturer | SmallRig |
|---|---|
| Material | |
| Maximum height | |
| Maximum load | |
| Minimum load | |
| Pan range | |
| Plate type | |
| Quick Release | |
| Spirit level | |
| Tilt range | |
| Tripod head | |
| Tripod head mount |
What is the maximum load capacity?
The maximum load weight is 8 kg.
Which quick release plates are compatible?
It uses a Touch-and-Go plate and is compatible with the Manfrotto 501PL quick release plate.
Can the handle be moved to the left side?
Yes, the detachable telescopic handle can be rotated and attached to both the right and left side.
Does it support bowl adapters?
Yes, it is compatible with 75 mm bowl adapters.
